MEI120 CX (4FT)

Category: AIR CURTAIN

Model:MEI150 CX

Ask Price

Your email address will not be published. Required fields are marked *

Description

• Standard height of curtain formed : UP TO 10 FT • Speed Maximum Air Velocity at Nozzle Discharge (CFM) : High 22 m/s & low 18 m/s • Noise level at a distance of 10’ from the curtain Db : 55 DB • No. of Blower : 4 BLOWERS • No. of Motors : 120w-2 (2 Motors) • Phase : Single Phase • RPM : 2800 RPM • Air Curtain thickness : 1 mm & 1.2MM • Body Material : ALL MS POWDER COATING • motor No. of Shaft : 2 Double Shaft • Blower : ABS • Electrical Motor: MNC BRAND • Maintenance Points for oiling : Not Required • . % Insect / dust rejection : 80% • Air Curtain Operation : Electrical • Weight (Approx) Kgs.18 • Motor HP : 0.20 HP • Motor winding : Cooper winding • Bearing : 2 RS sheel Bearing • Model : Sleek model

Additional Information

Model MEI150 CX
Height UP TO 10 FT
Weight 23kg
