Description
• Standard height of curtain formed : UP TO 10 FT
• Speed Maximum Air Velocity at Nozzle Discharge (CFM) : High 22 m/s & low 18 m/s
• Noise level at a distance of 10’ from the curtain Db : 53 DB
• No. of Blower : 3 BLOWERS
• No. of Motors : 120w-1 80W-1 (2 Motors)
• Phase : Single Phase
• RPM : 2800 RPM
• Air Curtain thickness : 1 mm & 1.2MM
• Body Material : ALL MS POWDER COATING
• motor No. of Shaft : 1 Single, 1 Double Shaft
• Blower : ABS
• Electrical Motor: MNC BRAND
• Maintenance Points for oiling : Not Required
• . % Insect / dust rejection : 80%
• Air Curtain Operation : Electrical
• Weight (Approx) Kgs.15
• Motor HP : 0.20 HP
• Motor winding : Cooper winding
• Bearing : 2 RS sheel Bearing
• Model : Sleek model
Additional Information
| Model | MEI 090 CX |
|---|---|
| Height | UP TO 10 FT |
| Weight | 15Kg |
