Description
• Standard height of curtain formed : UP TO 10 FT
Speed Maximum Air Velocity at Nozzle Discharge (CFM) : High 22 m/s TO 18 M/S
• Noise level at a distance of 10’ from the curtain Db : 55 DB
• No. of Blower : 4 BLOWERS
• No. of Motors : 120w-2 (2 Motors)
• Phase : Single Phase
• RPM : 2800 RPM
• Air Curtain thickness : 1 mm
Body Material : ALL BODY ss304 sleek model
• motor No. of Shaft : Double Shaft
• BLOWER : ABS HAVY DUTY
• ELECTRICAL MOTOR: MNC BRAND
• Maintenance Points for oiling : No require
• .%Insect / Dust : 80%
• Air Curtain Operation : Electrical
• Weight (Approx) Kgs. 18
• Motor HP : 0.20 HP
• Motor winding : Cooper winding
• Bearing : 2 RS sheel Bearing
Overall Dimensions : L 1200 MM W 210 MM H 225 MM
Additional Information
| Model | MEI120 SS3 (4FT) |
|---|---|
| Height | UP TO 10 FT |
| Weight | 15Kg |
